U-N20AGB
Leison Motor
850110
Electrical Specifications
Motor with Gearbox
| Model | Ratio | Voltage (v) | No Load | At Maximum Efficiency | Stall | |||||
| Speed (r/min) | Current (mA) | Speed (r/min) | Current (mA) | Torque (g.cm) | Output (w) | Torque (g.cm) | Current (mA) | |||
| N20AGB1000-07280 | 1/1000 | 5 | 10 | 40 | 9 | 65 | 600 | 0.30 | 3600 | 380 |
| N20AGB1000-09168 | 1/1000 | 6 | 21 | 60 | 19 | 130 | 1000 | 0.35 | 5500 | 820 |
| N20AGB380-06350 | 1/380 | 5 | 21 | 20 | 17 | 60 | 400 | 0.15 | 1100 | 180 |
| N20AGB100-09168 | 1/100 | 3 | 100 | 50 | 80 | 180 | 180 | 0.15 | 600 | 450 |
| N20AGB150-08195 | 1/150 | 6 | 120 | 45 | 100 | 120 | 200 | 0.18 | 1200 | 580 |
| N20AGB100-08230 | 1/100 | 12 | 300 | 50 | 150 | 180 | 350 | 0.35 | 1800 | 950 |
| N20AGB50-09168 | 1/50 | 6 | 420 | 70 | 320 | 230 | 160 | 0.20 | 800 | 900 |
| N20AGB50-08230 | 1/50 | 12 | 580 | 50 | 440 | 230 | 250 | 0.27 | 1300 | 950 |
| N20AGB500-09220 | 1/500 | 5 | 28 | 35 | 23 | 130 | 600 | 0.4 | 1000 | 520 |
| N20AGB500-10190 | 1/500 | 2.4 | 19 | 35 | 13 | 150 | 500 | 0.5 | 1000 | 370 |
| N20AGB100-11120 | 1/100 | 6 | 290 | 110 | 240 | 350 | 300 | 1650 | 1700 | |
| * Note: It’s only typical technical data, special requirement can be customized. | ||||||||||
Gearbox Data
| Reduction Ratio | 50 | 63 | 100 | 150 | 210 | 250 | 298 | 340 | 380 | 500 | 1000 |
| L | 9 | 12 | |||||||||
| Direction Of Rotation | CCW | CW | |||||||||
Dimensions
* Note: The motor parts such as shaft size, encoders, cables & connectors can be customized.
